48V DC Battery Plus
- • Long cycle life
- • Compact modular integration
- • Parallelizble for scalability
- • High energy efficiency, long service life
- • High operational reliability
certification
certification
| Model | UF5000 | U5000M | 7ULF | 7ULM |
| Chemistry | Li-ion Battery(Li-FePO4) | Li-ion Battery(Li-Mn) | Li-ion Battery(Li-FePO4) | Li-ion Battery(Li-Mn) |
| Nominal Voltage | 51.2V | 51.8V | 51.2V | 51.8V |
| Nominal Capacity @C5 | 100Ah | 100Ah | 100Ah | 100Ah |
| Nominal Energy | 5120Wh | 5180Wh | 5120Wh | 5180Wh |
| Max. Discharge Current | 100A | 100A | 200A | 200A |
| Cycle Life @80% DOD | >6000 cycles | >3000 cycles | >6000 cycles | >3000 cycles |
| Size W * H * L(mm) | 483*311*600 | 483*311*600 | 483*311*600 | 483*311*600 |
| BMS | Integrated | Integrated | External | External |
| OperationTemperature | 0 - 45℃ | 0 - 45℃ | 0 - 45℃ | 0 - 45℃ |
| Model | BF485080 | BM485080 |
| Chemistry | Li-ion Battery(Li-FePO4) | Li-ion Battery(Li-Mn) |
| Nominal Voltage | 51.2V | 51.8V |
| Nominal Capacity @C5 | 50Ah | 50Ah |
| Nominal Energy | 2560Wh | 2590Wh |
| Max. Discharge Current | 80A | 80A |
| Cycle Life @80% DOD | >6000 cycles | >3000 cycles |
| Size W * H * L(mm) | 320*280*350 | 300*280*350 |
| BMS | Integrated | Integrated |
| Operation Temperature | 0 - 45℃ | 0 - 45℃ |
For Golf cart,traction,marine,Telecom backup power(TBS),Off grid and On grid Solar system,Standelone energy storage,Back-up,etc...
The parameters above are only for reference. For more information, please consult EEMB.
