certification
| Model |
Nominal Voltage (V) |
Nominal Capacity (mAh) |
Standard Discharge Current (mA) |
Max.Discharge Current (mA) | Dimension(mm) |
Approx. Weight(g) |
||
| Continuous | Pulse | Diameter | Height | |||||
| CR1220 | 3.0 | 40 | 0.2 | 1 | 5 | 12.5 | 2.0 | 0.8 |
| CR1225 | 3.0 | 50 | 0.2 | 1 | 5 | 12.5 | 2.5 | 1.0 |
| CR1616 | 3.0 | 50 | 0.1 | 2 | 10 | 16.0 | 1.6 | 1.2 |
| CR1620 | 3.0 | 70 | 0.1 | 2 | 10 | 16.0 | 2.0 | 1.3 |
| CR1632 | 3.0 | 120 | 0.1 | 2 | 10 | 16.0 | 3.2 | 1.6 |
| CR2016 | 3.0 | 85 | 0.2 | 2 | 10 | 20.0 | 1.6 | 1.7 |
| CR2025 | 3.0 | 150 | 0.4 | 3 | 15 | 20.0 | 2.5 | 2.4 |
| CR2032 | 3.0 | 210 | 0.2 | 3 | 15 | 20.0 | 3.2 | 3.0 |
| CR2330 | 3.0 | 250 | 0.4 | 3 | 20 | 23.0 | 3.0 | 4.0 |
| CR2354 | 3.0 | 500 | 0.4 | 3 | 20 | 23.0 | 5.4 | 5.7 |
| CR2430 | 3.0 | 270 | 0.4 | 3 | 20 | 24.5 | 3.0 | 4.3 |
| CR2450 | 3.0 | 550 | 0.4 | 3 | 20 | 24.5 | 5.0 | 6.2 |
| CR2477 | 3.0 | 1000 | 2.0 | 5 | 30 | 24.5 | 7.7 | 9.5 |
| CR3032 | 3.0 | 500 | 0.4 | 5 | 25 | 30.0 | 3.2 | 6.8 |
High Temperature Version: (Operational temperature range:-40℃ to + 125℃)
Consult EEMB when using batteries at temperature beyond the -40℃to +125℃ range.
| Model |
Nominal Voltage (V) |
Nominal Capacity (mAh) |
Standard Discharge Current (mA) |
Max.Discharge Current (mA) | Dimension(mm) |
Approx. Weight(g) |
||
| Continuous | Pulse | Diameter | Height | |||||
| CR2450S | 3.0 | 550 | 0.2 | 3 | 20 | 24.5 | 5.0 | 6.8 |
| CR2032S | 3.0 | 210 | 0.2 | 3 | 15 | 20.0 | 3.2 | 3.0 |
| CR1632S | 3.0 | 110 | 0.1 | 2 | 10 | 16.0 | 3.2 | 2.0 |
Low Temperature Version: (Operational temperature range:-40℃ to + 70℃)
Consult EEMB when using batteries at temperature beyond the -40℃to +70℃ range.
| Model |
Nominal Voltage (V) |
Nominal Capacity (mAh) |
Standard Discharge Current (mA) |
Max.Discharge Current (mA) | Dimension(mm) |
Approx. Weight(g) |
||
| Continuous | Pulse | Diameter | Height | |||||
| CR2450L | 3.0 | 580 | 0.4 | 3 | 20 | 24.5 | 5.0 | 6.8 |
| CR2032L | 3.0 | 210 | 0.2 | 3 | 15 | 20.0 | 3.2 | 3.0 |
| CR1632L | 3.0 | 120 | 0.2 | 2 | 10 | 16.0 | 3.2 | 2.0 |
High Capacity Version: (Operational temperature range:-20℃ to + 60℃)
Consult EEMB when using batteries at temperature beyond the -20℃to +60℃ range.
| Model |
Nominal Voltage (V) |
Nominal Capacity (mAh) |
Standard Discharge Current (mA) |
Max.Discharge Current (mA) | Dimension(mm) |
Approx. Weight(g) |
||
| Continuous | Pulse | Diameter | Height | |||||
| CR2450H | 3.0 | 600 | 0.4 | 3 | 20 | 24.5 | 5.0 | 6.5 |
| CR2032H | 3.0 | 230 | 0.2 | 3 | 15 | 20.0 | 3.2 | 3.0 |
The parameters above are only for reference. For more information, please consult EEMB.
